Energy Storage Battery

PowerFly 6.0

Wall-mounted / Ground-mounted

5KWH/10KWH/16KWH/20KWH

Features

📱

Remote fault diagnosis, system upgrades, maintenance and real-time monitoring from anywhere.

🧠

OCV intelligent algorithm calibration ensures precise SOC accuracy and battery optimization.

🌧️

Designed to withstand harsh weather, dust, heavy rain and demanding outdoor environments.

⚡

Modular architecture supports up to 15 batteries connected in parallel.

Performance Specifications

Model	HZEB-LCT-5	HZEB-LCT-10	HZEB-LCT-16	HZEB-LCT-20
Battery Type	LiFePO₄	LiFePO₄	LiFePO₄	LiFePO₄
Nominal Voltage	51.2V	51.2V	51.2V	51.2V
Capacity (Ah)	100Ah	206Ah	314Ah	410Ah
Nominal Energy	5.12kWh	10.54kWh	16.07kWh	20.99kWh
Usable Energy	4.61kWh	9.49kWh	14.47kWh	18.89kWh
Max Charge/Discharge	100A	100A	150A	200A
Cycle Life	6000+	6000+	8000+	6000+
Cumulative Discharge Capacity	8.2MWh	16.9MWh	25.8MWh	33.7mwh
Warranty	5 + 5 Years	5 + 5 Years	5 + 5 Years	5 + 5 Years

SECURITY AND CERTIFICATION
Safety(Pack)	UN38.3,MSDS,IEC62619(CB),CE-EMC,IEC63056
Safety(Cell)	UN38.3,MSDS,IEC62619,CE,UL1973,UL2054

ENVIRONMENTAL SPECIFICATIONS
Operating Temperature Range(℃)	Charge 0℃~55℃;Discharge-20℃~55℃
Altitude(m)	≤2000m
Humidit	≤90%(Non-condensing)
